Halcro MC30 3ch Amplifier

R30,000.00

It is summer and Denver often sees temperatures in the high 90s. It is summer and gasoline is $4 a gallon, which hopefully is a situation that we will look back on in amazement that it ever cost so much, and not that it ever cost so little. Food costs are up, too. The house air conditioner is running almost 24/7 taking money out of my wallet in direct proportion to the cold air blowing into my house. I need an amplifier that runs cool and sips electricity like a hybrid Prius sips gas. It needs to sound good, too.

Halcro has become well known as the maker of some of the world’s best – and most expensive – solid state amplifiers. Their Halcro Logic product line targets the home theater market and carries prices that allow a far greater number of people to realistically consider becoming Halcro owners. According to the Web site, the Halcro Logic MC20, list $5000, uses “LYRUS™ technology to ensure the maximum detail and impact is drawn from all soundtracks.

“Class-D amplifiers (analogue) suffer from intrinsic distortion, that is, even with “perfect electronic components” the circuits mathematically generate distortion. This intrinsic distortion increases rapidly with both increasing power and frequency. Thus at high powers, class-D amplifiers hitherto are substantially inferior to well designed traditional class-A or -AB or -B amplifiers.

“The Lyrus™ circuits contain patented distortion canceling circuitry so that at high powers the Lyrus™ class-D amplifiers are on a par with well designed traditional class-A or -AB or -B amplifiers. Technically the intrinsic distortion can be attributed to an intrinsic time distortion (advanced phase) which varies in a non-linear manner with signal level (level squared law). The Lyrus™ circuits introduce a compensating time variation to the reference clock signal which controls when the output signal switches.

“The Lyrus™ amplifiers produce about 1/5th to 1/10th of the distortion of typical well designed competitors at high powers.” (Quotes from http://www.halcro.com/logic/lyrus.asp.)

Halcro specs the amplifier as being 94% efficient at converting electricity from the wall into electrical energy going to your speakers. Power consumption is 14 Watts idle and only 22 Watts when the amplifier is driving 350 Watts into a 4 Ohm load. I don’t understand either! How can you get 350 Watts out with only 22 Watts in? Whatever the physics are used to seemingly defy (Halcro) logic, it works: the amplifier becomes just slightly warm to the touch at any volume. (A follow-up with Halcro clarified this seemingly impossible specification. The amplifier consumes 22 Watts when it is putting out 350 Watts to the speakers. The total power drawn from the mains is actually 372 Watts.) The amplifier is rated at 400 Watts per channel into 4 Ohms at 0.007% THD (@1kHz). The input impedance is on the low side at 10k Ohms balanced XLR or unbalanced RCA. The weight is a reasonable 47 pounds. There are front panel blue LEDs for power and to indicate faults in either channel. There are remote power triggers, and Ethernet and RS232 connections, too, for complex home theater or specialized installations.

The power switch is on the rear panel. The front panel power button switches the amplifier mode between standby and on. The MC20 will operate on any voltage input from 100-240V with no internal modification and is shipped with both US and European power cords. The only gripe I have about installation results from the speaker binding posts. They are plastic covered CE approved which require the speaker cables to be inserted in one direction only. The wire direction of the left channel pair of binding posts position the speaker cables directly on top of the power cord.

The sound of the MC20 is a welcome surprise. I have listened to several other “digital” amplifiers. They each had their charms, but none presented a complete musical picture. There is usually good impact and control in the bass, but with a lack of resolution and low-level detail. In the treble, other Class D amps often exhibit decreasing resolution with increasing frequency which is probably a result of the filters used to remove the amplifier’s switching frequency from the audio signal. Their handling of the frequency extremes was a deal breaker for a satisfying long-term relationship.

The MC20 is different than these Class D amplifiers. The first hour or two of listening to a new component, after break-in and warm up, usually provides a reasonably complete objective impression of the sound. The characteristics of soundstage size, transient speed, resolution, bass power, midrange neutrality, and extension into the low bass and upper treble are apparent early in the audition. It usually takes days or weeks to understand the nuances of why a component moves me musically, or why it does not. I noticed no problems during that early get acquainted period, just the desire to hear more music through the MC20. We’re off to a good start.

I mentioned the soundstage above, so let’s begin with this important parameter. The MC20 carves out space like few other amplifiers. Each performer obviously occupies a specific location in space, both laterally and in the depth dimension. Individual performers are slightly less 3-dimensional compared to the tubed Manley Neo-Classic 250 amplifiers, but certainly competitive with any other solid state amplifier I have heard up to about $10,000, including the $9500 Conrad Johnson Premier 350, $7500 Pass X250.5, and $6500 BAT VK250SE. There is no blurring of images, just an easy ability to look directly at any sound and clearly discern the size and location of the performer, which is often outside of the space between the speakers. In fact, the excellent imaging ability of the Halcro amp made the speakers disappear more than usual. A competent analog source will demonstrate this convincingly.

Transient speed, often called rise time, impact, macro-dynamics, and punch, is among the best of any amplifier in existence today. There is a clear and forceful leading edge to every sound. This is especially noticeable on percussion. That instantaneous – and instantaneously gone – touch of a drumstick on a drum head or cymbal is presented completely unambiguously. This makes drums sound especially realistic. I gained a new appreciation for good drummers. The differences between snare and tom have never been more apparent. The subtle tap, tap, tapping on a cymbal is clear and clearly enjoyable. I do not recall being startled and amazed more often by these fleeting sounds by any other amplifier. Ever. The MC20 does not “turn on a dime”, it turns on an electron! The dynamic performance of the MC20 is easily world-class and makes many (most?) other amplifiers sound soft and slow. This does not mean that the MC20 is a hard or cold sounding component – far from it.



The MC20’s transient ability could just be a hollow trick if the “baby Halcro” did not have the finesse to carry it off by allowing a very high quality of succeeding micro-harmonic content to shine through 100% of the time. All amplifiers (and other components, too) walk a fine line between sheer speed and a golden enveloping warmth. This is similar to the bit depth on digital images. At 24-bit, you see 16.7 million colors. At 1-bit, the image is either black or white. The MC20 is far, far closer to full resolution 24-bit panoramas than to stark, bleached 1-bit images.

The MC20 can boogie with the best. Listen to “Day at the Dog Races” on Little Feat’s Time Loves a Hero LP (Warner Brothers BS3015). With exceptional timing and pace, the MC20 takes you on a wild ride that is great fun. The sound is relaxed, resolved, and rewarding at any volume level. Again, that powerful leading edge dynamic ability is a definite attraction of the MC20.

The bass range is excellent, too. The bass is very deep and powerful, and the lowest notes that your speakers can produce will be offered with excellent power and control. The bass presentation is competitive or better than any of the amplifiers mentioned above. The sense of control, power, and more importantly, fine resolution is excellent by any measure or standard. The Manley 250s push just a bit more low-level bass detail to the speakers, but the Halcro wins for power and control. I have not heard Halcro’s $43,000 DM68 amplifiers in my room, but really had a hard time imagining how they could beat the MC20 in the bass. In other words, the bass of the MC20 is very satisfying.

So is the midrange and treble. In fact, the MC20 could easily join the “reference amplifier” category but for two reasons, one definable and one hauntingly imaginary. The Manley Neo-Classic 250s have somewhat more harmonic depth or low-level resolution in the upper midrange and treble. Good tube amplifiers often manage a small but important degree of humanness that helps singers to sound more present and alive. This is a common trait of many tube amplifiers over their solid-state competition. But let me be clear: this small – and I do mean small – relative deficiency of the Halcro is even smaller and less bothersome than I often heard from the solid-state competition mentioned above. These competitors also have serious issues in certain areas of the audible frequency spectrum that the Halcro avoids. For example, the BAT amp has a level of “texture” in the lower treble that is not conducive to relaxed enjoyment of most music. OK, I’ll come out and call it a fine grain. The Pass amp loses resolution and sweetness as the volume leaves Class A at 15 Watts and turns noticeably harder and colder at higher levels. The CJ amp has a different character in the midrange than the treble, making it sound discontinuous. The Halcro MC20 shares none of these deficiencies. The fact that the MC20 is fully competitive with the better performers at this level indicates just how good this “green” amplifier really is.

The imaginary reason to not include the MC20 in the reference category is probably just plain silly, but could result in not appreciating the significant strengths of the MC20 and simply enjoying the sound now and forevermore. It is the root of the poisonous “audiophile nervosa”: You know, just because this is the baby Halcro, that there are better amplifiers out there. The Marantz MA9S2 mono amplifiers, at $15,000 per pair, are one example. But for amplifiers which cost less than ten grand, the MC20 is unassailable.

Digital amplifiers usually have an excellent midrange, great separation of musicians, and a powerful dynamic punch. The MC20 owns these strengths. When the entire system is of the caliber of the MC20, the rules change. It is no longer a question of finding components with complementary colorations, but of the time consuming and painstaking task of eliminating the weakest links, one by one. The Halcro MC20 is an outstanding performer in its price range and above, and one you should hear in your system if for no other reason than as a data point in the evolution of Class D amplifiers.

Overall Rating: 9 LPs, borderline 9.5 LPs


Within a few years of entering the US market, Australian audio manufacturer Bruce Halcro Candy cemented his place in audio history by designing a amplifier that Paul Bolin said (in the October 2002 Stereophile) “could well justify the creation of a ‘Class A+’ amplifier category in ‘Recommended Components’,” and the low distortion characteristics of which prompted editor John Atkinson, a man who has elevated the craft of understatement to a high art, to reach for the word astonishing. That was the Halcro dm58 monoblock ($29,990/pair), which has only recently been superseded by the Halcro dm78.406halcro.jpg

In that one stroke, Candy became the unluckiest designer on earth, in the same sense that the great San Francisco band Moby Grape ran out of luck when their record label, Columbia, released eight songs from their debut album as four different singles—on the same day. What could you possibly do for an encore?

In the case of Moby Grape, while the merits of their subsequent albums are open to debate (I rather like Wow), there’s little question that their wad had in fact been shot. On the other hand, Bruce Candy focused his talents in a new direction, on a very different and altogether less expensive sort of product.

The result of his recent work, the Halcro Logic series of amplifiers, has at least one thing in common with the company’s more expensive Reference series: Both lines are the intended embodiments of Candy’s complete and utter loathing of distortion, and his desire to shrink and then kill it, Grover Norquist style. Stereophile‘s readers have already heard how he did that the first time around; today, some five years after the release of the groundbreaking dm58, Candy is making something very different and very new: a class-D amplifier.

You say distortion like it’s a bad thing
Well, class-D isn’t entirely new, having been toyed with as early as the 1950s. Nor does the D in class-D stand for digital: After classes A through C had been described and created, D was simply the next letter up for grabs (footnote 1).

Even so, and notwithstanding the fact that a class-D amp doesn’t necessarily have a digitized throughput, it does behave in a digital manner: Its output devices, typically in complementary pairs, are used purely as switching devices, and so their output signal, if left unmodulated (I’ll come back to that), is either a 1 or a 0—meaning the device is either fully on or fully off. Think of it this way: Driven by the raw output of a class-D amp, a loudspeaker driver would either come flying out of the enclosure toward the listener’s nose, or struggle equally hard to escape its moorings in the other direction, with nothing in between.

Coaxing the driver into moving in and out is what you want the amplifier to do, of course, but preferably with more in the way of finesse—and, ideally, in mimicry of the continuum that is sound. So you have to put something in front of the class-D output section to control, with near-infinite speed and accuracy, the ratio of time that those output devices spend between being on and being off—which is to say, you have to modulate the output. Most designers of class-D amps do that with an analog technique that has a digital-sounding name: pulse-width modulation.

That’s easy: Add a fixed, very-high-frequency carrier signal from a triangular wave oscillator to the input, alongside the audio signal, and make an active circuit—you could even use a tube, I suppose—to compare the two and to then send the difference between them to the switching output devices. Let a higher-amplitude portion of the audio signal equal a wider, positive-going pulse, a low-amplitude part of the wave equal a wider, negative-going pulse, and so forth. Now you’ve given the output devices an analog blueprint to follow, and their own output is amplified sound—or at least it will be, once you perform the final trick of filtering out that triangular wave’s harmonics and a few other nasties.

It’s an efficient amplifier, because those switching devices don’t require any bias current. It’s also a compact amplifier, for the same reason and because MOSFETs that are up to the task can be made very small. But is it a clean amplifier? I’m sure the boys at Stereo Review would have thought so, but let me remind you: Bruce Halcro Candy hates, and I mean really hates, distortion. And in addition to the switching noise that you’d imagine is part and parcel of a system such as this (think of a class-D amp as an audio-frequency switch-mode power supply), he’s identified a distortion that, in his words, is mathematically intrinsic to a class-D amplifier with pulse-width modulation: The shape of the triangular carrier wave becomes distorted—is actually rendered asymmetrical—while the amplifier is in use, resulting in a nonlinear phase advance in the final output. Which ain’t good.

So Candy, in his quest to cancel out every last iota of distortion, developed a circuit that actively modulates the carrier wave and corrects its symmetry during amplification. The Halcro company has appended the trade name Lyrus to this distortion-canceling circuitry, but you could also call the technique carrier-symmetry modulation: That, in fact, is what Bruce Candy called it in a paper he delivered to the AES convention in 2004, a copy of which I’ve been trying, with only limited success, to fathom.

MC, phone home
The Logic MC20 ($4990) is Halcro’s entry-level Lyrus amp; in fact, it’s Halcro’s least expensive amplifier, period. In addition to the unique class-D circuitry described above, the 400Wpc MC20 offers a choice between unbalanced and true balanced inputs, an apparently sophisticated switch-mode power supply, and current-sensing and thermal-protection circuits that keep the MC20 from going postal on itself or the user’s loudspeakers.

In the unlikely event that a glitch does occur, the MC20 and its owner can fall back on Plan B, which is called HRAS—for Halcro Reliability Assurance Service. Every Halcro Logic component has RS-232 and Ethernet sockets on its rear panel and is supplied with a CD of HRAS software, complete with high-level user interface, ready to be installed on the Windows XP-based PC of choice. With the amp connected to the computer, the HRAS software loaded, and the computer logged on to the Internet, a malfunctioning MC20 can literally call the nearest Halcro distributor, report the fault, and have a new board or perhaps a whole new amplifier delivered by air freight before the owner knows there’s anything wrong. As a parent, I can’t help being reminded of the time my daughter had a tiff with a playmate at the other child’s house, called me using their phone, and cried, “Daddy, come get me now!” (footnote 2) (And as someone who has recently had to jump through flaming hoops of bureaucracy to get his Sony SACD player through the front door of a factory service facility, I can’t help being very impressed.)

Overall, in a technical sense, I’m hard-pressed to think of anything that differs more from my low-output, tube-powered, single-ended, class-A monoblock amplifiers (the Lamm ML2.1s) than this high-output, solid-state, push-pull, class-D stereo amplifier. More to the point, Halcro’s US high-end representative, the thoroughly genial Philip O’Hanlon, was well aware of that fact when he suggested that I give the Halcro a spin in my system and write this review. Talk about courage.




Footnote 1: It’s a good thing audio engineers don’t use the Etruscan alphabet for naming their operating classes; otherwise, the fourth class of operation would have to be called Class F, which would elicit much snickering from the back of the room.Footnote 2: But this is a slippery slope: Could an HRAS-enabled amp harvest the user’s credit-card number from an unsecure page and buy a new preamp for itself? Could it notify the federal government if the user plays politically unacceptable music (I’m thinking Phil Ochs here), or call the local drug squad if it senses that “Interstellar Overdrive” has been repeated too many times in a single listening session? The implications are staggering.

Description

FEATURES:

  • Power Output: 400W RMS continuous into 4 Ohms
  • Distortion THD: <0.007% at 1kHz at all powers up to 400W into 4 Ohms, <0.03% at 7kHz at all powers up to 400W
  • Unbalanced and Balanced Voltage Inputs
  • Mains Voltage: 100 – 120VAC or 190 – 250VAC
  • Remote trigger switch between On & Standby
  • Command Functions:
    • Switch between On & Standby
    • Ability to inhibit individual amplifier modules
    • Amplifier module will indicate Over Temperature condition
  • Halcro Reliability Assurance Service



SPECIFICATIONS:

Power Output

  • 400W RMS continuous into 4 Ohms
  • Frequency Response (-3db) 5 Hz – 45kHz

Audio
Inputs, selectable

  • Unbalanced: RCA sockets
  • Balanced: XLR sockets

Outputs

  • Internally bridged: Binding Posts
